Valv boul twa-fason Threaded
Twa-fason Threaded boul valv
[Apèsi sou pwodwi a nan twa-fason Threaded boul valv]
1. Presyon nominal: 1.6-6.4MPa
2. Ranje estabilite aplikab: -20-232 degre -350 degre
3. Medya aplikab: dlo, lwil oliv, gaz ak kèk likid korozivite (WOG)
4. Kalite fil: G. NPT. BSPT. BSP. DI259/2999
[Aplikasyon ranje valv boul twa-fason Threaded]
Li ka aplike nan divès kalite medya tankou dlo, vapè, lwil oliv, asid nitrique, asid acetic, dlo sèl amonyak, dlo netralize ak sou sa.
Syèj valv la adopte yon estrikti sele elastik, ki asire sele serye ak fasil ouvèti ak fèmen.
Tij valv la adopte yon estrikti anba-monte ak yon sele Envèse. Lè kavite valv la anòmal presyon, tij valv la pa pral afekte.
Yon mekanis pwezante switch 90 degre ka mete kanpe ak fèmen jan sa nesesè pou anpeche move operasyon.
Apwopriye pou PN1.0-4.0MPa, tanperati k ap travay -29-180 degre (bag sele a se ranfòse polytetrafluoroethylene) oswa -29-300 degre (
Bag la sele se para-polystyrène) sou divès kalite tiyo, yo itilize koupe oswa konekte mwayen an nan tiyo a.
[Pwensipal pati ak materyèl nan twa-fason Threaded boul valv]
| pati | materyèl |
| kò valv | asye CF8M/CF8 |
| bouchon valv | asye CF8M/CF8 |
| boul | asye CF8M/CF8 |
| gasket boul | PYE |
| baton valv | asye CF8M/CF8 |
| ranmase | PYE |
| gwo flak | PYE |
| Nwa konpresyon | asye CF8M/CF8 |
| manch | asye CF8M/CF8 |
| siy direksyon koule | Aliminyòm |
| Wasabi | asye CF8 |
| bouchon nwa | asye CF8 |
| aparèy bloke | asye CF8 |
| ka kwi | plastik |
| kouvèti avèg | asye CF8M/CF8 |
| GRANDÈ | d | L | H | D1 | B | F | G | W1 | W2 | h |
| 1/2" | 12.7 | 75 | 59 | 126 | 71.0 | 33.5 | 37.5 | 22.4 | 35.0 | 10-20UNC |
| 3/4" | 16.0 | 85 | 64 | 126 | 81.5 | 39.0 | 42.5 | 22.4 | 35.0 | 10-20UNC |
| 1" | 20.0 | 100 | 80 | 145 | 102.0 | 50.5 | 51.5 | 22.4 | 35.0 | 10-20UNC |
| 1-1/4" | 25.0 | 115 | 90 | 145 | 108.5 | 51.0 | 57.5 | 22.4 | 35.0 | 10-20UNC |
| 1-1/2" | 32.0 | 125 | 96 | 204 | 121.0 | 58.0 | 63.0 | 22.4 | 38.1 | 1/4-20UNC |
| 2" | 38.1 | 148 | 106 | 204 | 138.5 | 65.5 | 73.0 | 22.4 | 38.1 | 1/4-20UNC |
telechaje Google:
1. ① Non pwodwi ak modèl valv boul twa-fason ② Kalib valv boul twa-fason ③ Kit valv boul twa-fason an vini ak Pwodwi pou Telefòn pou nou ka chwazi modèl ki kòrèk la pou ou.
2. Si modèl valv boul twa-fason Zhenggang Valv te chwazi pa inite konsepsyon an, tanpri bay lòd dirèkteman nan depatman lavant nou an dapre modèl valv boul twa-fason an.
3. Lè okazyon an itilize trè enpòtan oswa anviwònman an konplèks, tanpri eseye pi byen ou a bay desen konsepsyon ak paramèt detaye, ak ekspè valv nou yo pral revize epi tcheke yo pou ou.
